Plent Firefighting Electric Fire Monitor’s operation mode is though remote unit or joystick. Plent R&D team can adjust motor’s working voltage to 12VDC or 24VDC to meet different vehicle mounting requirements. Personnel can easily operate the firefighting electric fire monitor in vehicle’s cabinet. This is quite simple for every users.
Plent Firefighting Electric Fire Monitor’s operation mode is though remote unit or joystick. Plent R&D team can adjust motor’s working voltage to 12VDC or 24VDC to meet different vehicle mounting requirements. Personnel can easily operate the firefighting electric fire monitor in vehicle’s cabinet. This is quite simple for every users.
Product |
Plent Firefighting Electric Fire Monitor-C Series |
||
Model# |
PSKD8/20W-C |
PSKD8/30W-C |
PSKD8/40W-C |
Working Pressure |
8Bar / 116PSI |
8Bar / 116PSI |
8Bar / 116PSI |
Flow Rate |
1200lpm (320GPM) |
1800lpm (475GPM) |
2400lpm (635GPM) |
Max Reach |
≥53m |
≥60m |
≥65m |
Flow Tolerance |
+10% |
||
Travel Range |
0°~360° (Horizontally)/-45°~+90°(vertically) |
||
Turning Speed |
12°/sec. (Horizontally) / 12°/sec.(Vertically) |
||
Jetting Pattern |
Jet or Fog Spray |
||
Max Fog Angle |
120° |
||
Working Voltage |
AC220V or DC 12V/24V (customized available) |
||
Monitor Inlet |
2.5”Flange or Bigger Size ( available for customized design) |
||
Monitor Outlet |
2.5”(63.5mm) |
||
Weight (N.W.) |
18.5kg (50.8 lbs) |
||
Waterway Size |
2.5”(63.5mm) |
||
Product Material |
Aluminum Alloy (Nozzle and Monitor Body) |
||
Trademark |
Shengxin Firepro Tech or Customized |
Plent Firefighting Electric Fire Monitor – C Series is capable to work in severe and harsh fighting, mining, chemical industries environment. Fore more info., please kindly refer to below tech data sheet.
1. Durable and Light Product Construction
2. High Waterproof Protection for Electric Parts
3. Imported Key Parts (Motor and Sensor)
4. Flexible Oscillation and Travel Limit Setting
5. Extra Manual Operation Function for emergency case
6. Professional Engineer Team for Aftersales and Tech Supports
7. Reliable, Leakproof DT connector for easy cable connection.
8. 1-Year Warranty
● Oil & Gas
● Fuel Storage Area
● Fire & Rescue
● Mining
● Sea Conditions
● Chemical Industry
For More info about Ningbo Plent Firefighting Electric Fire Monitor products, feel free to contact us any time.
